Gigabyte Aoruos Gen4 AIC Adapter

Gigabyte Aoruos Gen4 AIC Adapter Support 4 x PCIe 4.0 M.2 SSD Model number: GC-4XM2G4

Gigabyte Aoruos Gen4 AIC Adapter
Model number: GC-4XM2G4

Product features:
.Through the AORUS Storage Manager application, effortlessly construct disk arrays, with full support for PCIe 4.0 design and a cooling solution specifically tailored for PCIe 4.0 SSDs.
.4 sets of PCIe 4.0 / 3.0 M.2 slots.
.Independent control chip with full PCIe Express 4.0 support.
.Cooling solution designed specifically for PCIe 4.0 SSDs.
.One-click RAID setup for easily achieving remarkable performance.
.Customizable AORUS Storage Manager application.
With the AORUS Gen4 AIC expansion card paired with four sets of PCIe 4.0 2TB SSDs, a disk array can be constructed, achieving astonishing read and write speeds of up to 15,000 MB/s.

Specification
Interface:
PCI Express x16, compatible with PCI Express x16 and x8 slots(If the adaptor card is installed in a x8 slot, only the M2_1 and M2_2 connectors can be used.)

LED:
4 x M.2 activity LEDs
Storage Interface:
4 x M.2 connectors (Socket 3, M key, type 2242/2260/2280/22110 PCIe x4 SSD support)
Support for RAID 0, RAID 1, and RAID 10*
* Supported RAID levels vary by platform.
Dimension:
26.2cm x 11.5cm
